MAX8559EBAJJ+T
IC REG LINEAR 2.85V/2.85V 8UCSPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX8559EBAJJ-T is a dual 300mA positive fixed output linear voltage regulator. This component features two independent regulators, each capable of delivering 300mA with a fixed output voltage of 2.85V. With a low dropout voltage of 0.12V at 100mA, it offers efficient power regulation. The device includes enable control and protection features such as over current, over temperature, and short circuit protection. The quiescent current is rated at 290 µA. The MAX8559EBAJJ-T operates with an input voltage up to 6.5V and boasts a high power supply rejection ratio (PSRR) ranging from 70dB to 54dB across the 10kHz to 100kHz frequency spectrum. Its compact 8-UCSP (2.02x1.02) package is suitable for surface mount applications and is supplied on tape and reel. This regulator is commonly utilized in portable electronics and battery-powered devices.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-WFBGA, CSPBGA |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 300mA, 300mA |
| Operating Temperature | -40°C ~ 85°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 290 µA |
| Voltage - Input (Max) | 6.5V |
| Number of Regulators | 2 |
| Supplier Device Package | 8-UCSP (2.02x1.02) |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 2.85V, 2.85V |
| Control Features | Enable |
| PSRR | 70dB ~ 54dB (10kHz ~ 100kHz) |
| Voltage Dropout (Max) | 0.12V @ 100mA, 0.12V @ 100mA |
| Protection Features | Over Current, Over Temperature, Short Circuit |
