MAX1658ESA
IC REG LIN POS ADJ 350MA 8SOICManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX1658ESA is a versatile linear voltage regulator IC offering a positive adjustable output with a maximum current of 350mA. This component features an enable pin for control and is housed in an 8-SOIC package for surface mounting. With an input voltage range up to 16.5V and an output voltage adjustable from 1.25V to 16V, it provides flexibility for various power supply designs. Protection features include over current, over temperature, and reverse polarity, ensuring robust operation. The quiescent current is a low 60 µA, making it suitable for power-sensitive applications. This regulator is commonly employed in consumer electronics, industrial control systems, and medical devices.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | Adjustable (Fixed) |
| Mounting Type | Surface Mount |
| Current - Output | 350mA |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 60 µA |
| Voltage - Input (Max) | 16.5V |
| Number of Regulators | 1 |
| Supplier Device Package | 8-SOIC |
| Voltage - Output (Max) | 16V |
| Voltage - Output (Min/Fixed) | 1.25V (3.3V) |
| Control Features | Enable |
| PSRR | - |
| Voltage Dropout (Max) | 1.5V @ 350mA |
| Protection Features | Over Current, Over Temperature, Reverse Polarity |
