MAX1615EUK-T
IC REG LIN 3.3V/5V 30MA SOT23-5Manufacturer: Analog Devices Inc./Maxim Integrated
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX1615EUK-T is a dual-output linear voltage regulator. This device provides two fixed positive outputs of 3.3V and 5V, each capable of delivering up to 30mA. The regulator features an enable pin for power sequencing and shutdown control. Designed for efficient operation, it offers a low dropout voltage of 0.35V at the maximum output current. Protection features include overcurrent and overtemperature shutdown. The MAX1615EUK-T is housed in a compact SOT-23-5 package, suitable for surface mounting. Typical applications include battery-powered devices, portable electronics, and power management in various industrial systems. The operating temperature range is -40°C to 85°C.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-74A, SOT-753 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 30mA |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Voltage - Input (Max) | 28V |
| Number of Regulators | 1 |
| Supplier Device Package | SOT-23-5 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 3.3V, 5V |
| Control Features | Enable |
| PSRR | - |
| Voltage Dropout (Max) | 0.35V @ 30mA |
| Protection Features | Over Current, Over Temperature |
