DS3882E+T&R
IC CCFL CNTRL 100KHZ 28TSSOPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Lighting, Ballast Controllers
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated DS3882E-T-R is a CCFL controller IC designed for precise regulation of Cold Cathode Fluorescent Lamps. This component operates within a frequency range of 40kHz to 100kHz, offering adjustable dimming capabilities. It is housed in a 28-TSSOP package, suitable for surface mount applications. The device features a supply voltage range of 4.75V to 5.25V and consumes approximately 12 mA of supply current. Its operating temperature spans from -40°C to 105°C, ensuring reliable performance in demanding environments. This CCFL controller finds application in various lighting solutions, including automotive displays and industrial lighting systems. The DS3882E-T-R is supplied in tape and reel packaging for high-volume manufacturing.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Frequency | 40kHz ~ 100kHz |
| Type | CCFL Controller |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Supply | 4.75V ~ 5.25V |
| Supplier Device Package | 28-TSSOP |
| Dimming | Yes |
| Current - Output Source/Sink | - |
| Current - Supply | 12 mA |
