MAX16813BAUP/V+T

IC LED DRVR CTRLR PWM 20TSSOP

Manufacturer: Analog Devices Inc./Maxim Integrated

Categories: LED Drivers

Quality Control: Learn More

LED Driver IC 4 Output DC DC Controller SEPIC, Step-Up (Boost) PWM Dimming 150mA 20-TSSOP-EP

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 24 week(s)Product Status: ActivePackaging: Tape & Reel (TR)
Technical Details:
PackagingTape & Reel (TR)
Package / Case20-TSSOP (0.173"", 4.40mm Width) Exposed Pad
Voltage - Output-
Mounting TypeSurface Mount
Number of Outputs4
Frequency200kHz ~ 2MHz
TypeDC DC Controller
Operating Temperature-40°C ~ 125°C (TA)
ApplicationsBacklight, Lighting
Current - Output / Channel150mA
Internal Switch(s)No
TopologySEPIC, Step-Up (Boost)
Supplier Device Package20-TSSOP-EP
DimmingPWM
Voltage - Supply (Min)4.75V
Voltage - Supply (Max)40V
GradeAutomotive
QualificationAEC-Q100
