MAX16807AUI+TG069
IC LED DRV CTRL PWM 55MA 28TSSOPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: LED Drivers
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated's MAX16807AUI-TG069 is an 8-output DC-DC controller designed for LED driving applications. This SEPIC, step-down (buck), and step-up (boost) topology device features PWM dimming with a frequency range of 20kHz to 1MHz. Each of its 8 outputs can deliver up to 55mA. The controller operates from a supply voltage between 8V and 26.5V, with a maximum output voltage of 36V. It is housed in a 28-TSSOP-EP package, suitable for surface mounting. The device is rated for an operating temperature of -40°C to 125°C (TA). This component finds application in backlighting and general lighting systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-TSSOP (0.173"", 4.40mm Width) Exposed Pad |
| Voltage - Output | 36V |
| Mounting Type | Surface Mount |
| Number of Outputs | 8 |
| Frequency | 20kHz ~ 1MHz |
| Type | DC DC Controller |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Applications | Backlight, Lighting |
| Current - Output / Channel | 55mA |
| Internal Switch(s) | No |
| Topology | SEPIC, Step-Down (Buck), Step-Up (Boost) |
| Supplier Device Package | 28-TSSOP-EP |
| Dimming | PWM |
| Voltage - Supply (Min) | 8V |
| Voltage - Supply (Max) | 26.5V |
