MAX1582YETC
MAX1582 HIGH-EFFICIENCY STEP-UPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: LED Drivers
Quality Control: Learn More
LED Driver IC 2 Output DC DC Regulator Step-Up (Boost) Analog, PWM Dimming 650mA (Switch) 12-TQFN (4x4)
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 12-WQFN Exposed Pad |
| Voltage - Output | 25.5V |
| Mounting Type | Surface Mount |
| Number of Outputs | 2 |
| Frequency | 1MHz |
| Type | DC DC Regulator |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Backlight |
| Current - Output / Channel | 650mA (Switch) |
| Internal Switch(s) | Yes |
| Topology | Step-Up (Boost) |
| Supplier Device Package | 12-TQFN (4x4) |
| Dimming | Analog, PWM |
| Voltage - Supply (Min) | 2.6V |
| Voltage - Supply (Max) | 5.5V |
Request a Quote
