MAX6960EVKIT
EVAL KIT FOR MAX6960Manufacturer: Analog Devices Inc./Maxim Integrated
Categories: LED Driver Evaluation Boards
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX6960EVKIT, an evaluation kit for the MAX6960 LED driver IC. This evaluation board facilitates the testing and development of applications utilizing the MAX6960, which provides four non-isolated current-sinking outputs, each capable of driving up to 40mA. The kit is designed for a 5V input voltage and is supplied with the necessary boards for comprehensive evaluation. The MAX6960 is suitable for various display backlighting and general illumination applications where precise LED current control is required, commonly found in automotive, industrial, and consumer electronics.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Voltage - Output | - |
| Voltage - Input | 5V |
| Current - Output / Channel | 40mA |
| Utilized IC / Part | MAX6960 |
| Supplied Contents | Board(s) |
| Outputs and Type | 4 Non-Isolated Outputs |
Request a Quote
