MAX5916AEUI+
IC HOT SWAP CTRLR PCI 28TSSOPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Hot Swap Controllers
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX5916AEUI- is a 5-channel Hot Swap Controller designed for PCI applications. This device facilitates safe insertion and removal of PCI cards into live backplanes. Key features include internal switches and programmable current limiting, circuit breaker functionality, and auto-retry with fault timeout. The controller also incorporates thermal limit and undervoltage lockout (UVLO) protection. Operating with a supply voltage range of 10.8V to 13.2V, the MAX5916AEUI- offers output current capabilities up to 1A per channel, with a typical quiescent current of 2.5 mA. The device is supplied in a 28-TSSOP package for surface mounting. It is utilized in various industrial and telecommunications systems requiring robust hot-swapping capabilities.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Auto Retry, Fault Timeout, Thermal Limit, UVLO |
| Packaging | Bulk |
| Package / Case | 28-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Type | Hot Swap Controller |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 10.8V ~ 13.2V |
| Applications | PCI |
| Internal Switch(s) | Both |
| Current - Output (Max) | 205mA, 1A |
| Supplier Device Package | 28-TSSOP |
| Programmable Features | Circuit Breaker, Current Limit |
| Number of Channels | 5 |
| Current - Supply | 2.5 mA |
