MAX5048BAUT#G16
IC GATE DRVR LOW-SIDE SOT23-6Manufacturer: Analog Devices Inc./Maxim Integrated
Categories: Gate Drivers
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX5048BAUT-G16 is a single-channel, low-side gate driver housed in a SOT-23-6 package. This device features both inverting and non-inverting inputs, providing flexibility for various control schemes. With peak output currents of 1.3A source and 7.6A sink, it effectively drives N-channel MOSFETs. The operating supply voltage range is from 4V to 12.6V, with logic input thresholds at 0.8V for VIL and 2.4V for VIH. Typical rise and fall times are 82ns and 12.5ns, respectively. This component is suitable for applications in industrial power supplies, automotive systems, and battery-powered devices. It is supplied on tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-23-6 |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 4V ~ 12.6V |
| Input Type | Inverting, Non-Inverting |
| Supplier Device Package | SOT-6 |
| Rise / Fall Time (Typ) | 82ns, 12.5ns |
| Channel Type | Single |
| Driven Configuration | Low-Side |
| Number of Drivers | 1 |
| Gate Type | N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 0.8V, 2.4V |
| Current - Peak Output (Source, Sink) | 1.3A, 7.6A |
| Programmable | Not Verified |
