MAX78615+PPM/A03
IC ENERGY MEAS PROC 3PH TQFNManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Energy Metering
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX78615-PPM-A03 is a 3-phase energy metering IC housed in a 24-TQFN (4x4) package. This surface-mount component operates from a 3V to 3.6V supply voltage, drawing a typical current of 8.1mA. Optimized for precise energy measurement in three-phase systems, the MAX78615-PPM-A03 is utilized in applications such as industrial power monitoring and smart grid infrastructure. The device features I/O voltages ranging from 0.8V low to 2V high and is supplied in a tube. Its operating temperature range is -40°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 24-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 8.1mA |
| Measurement Error | - |
| Input Impedance | - |
| Voltage - I/O High | 2V |
| Voltage - I/O Low | 0.8V |
| Meter Type | 3 Phase |
| Supplier Device Package | 24-TQFN (4x4) |
| Voltage - Supply | 3 V ~ 3.6 V |
