MAX3055ASD
IC TRANSCEIVER FULL 1/1 14SOICManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Drivers, Receivers, Transceivers
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX3055ASD is a full CANbus transceiver designed for robust communication in demanding environments. This 1/1 transceiver operates at data rates up to 125kbps, ensuring reliable data transmission for automotive and industrial automation applications. Featuring a 14-SOIC package for surface mounting, the MAX3055ASD offers a wide operating temperature range of -40°C to 125°C, making it suitable for harsh conditions. The device operates from a supply voltage of 4.75V to 5.25V and includes 18mV of receiver hysteresis for improved noise immunity. Its full duplex capability facilitates simultaneous transmission and reception, crucial for efficient CANbus network operation.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Type | Transceiver |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply | 4.75V ~ 5.25V |
| Number of Drivers/Receivers | 1/1 |
| Data Rate | 125kbps |
| Protocol | CANbus |
| Supplier Device Package | 14-SOIC |
| Receiver Hysteresis | 18 mV |
| Duplex | Full |
