MX7545AKEWP+T
IC DAC 12BIT A-OUT 20SOICManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MX7545AKEWP-T is a 12-bit, single-channel, R-2R architecture digital-to-analog converter. This component features a parallel data interface and an external reference type, with analog and digital supply voltage ranges of 5V to 15V. The device offers a typical settling time of 1µs and operates within a temperature range of -40°C to 85°C. Its INL/DNL specifications are ±0.5 LSB (Max) and ±1 LSB (Max) respectively. Packaged in a 20-SOIC (0.295", 7.50mm Width) surface mount configuration, it is supplied on a tape and reel. The MX7545AKEWP-T is utilized in applications such as industrial control, data acquisition, and test and measurement equipment.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 21 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-SOIC (0.295"", 7.50mm Width) |
| Output Type | Current - Unbuffered |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Data Interface | Parallel |
| Reference Type | External |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 5V ~ 15V |
| Voltage - Supply, Digital | 5V ~ 15V |
| Settling Time | 1µs |
| Supplier Device Package | 20-SOIC |
| Architecture | R-2R |
| Number of D/A Converters | 1 |
| INL/DNL (LSB) | ±0.5 (Max), ±1 (Max) |
| Differential Output | No |
| Programmable | Not Verified |
