MX7225KEWG+T
IC DAC 8BIT V-OUT 24SOICManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MX7225KEWG-T is an 8-bit, quad-channel, voltage-output Digital to Analog Converter (DAC). This component features an R-2R architecture and a parallel data interface, offering a ±1 LSB maximum Integral Linearity Error (INL) and Differential Non-Linearity (DNL). The device requires external reference voltage and operates within an analog supply range of 11.4V to 16.5V and -5V, with a digital supply range of 14.25V to 15.75V. It boasts a fast settling time of 4µs for a full-scale step. The MX7225KEWG-T is housed in a 24-SOIC package (0.295" width) and is supplied on tape and reel. This component is commonly utilized in industrial control systems, data acquisition, and instrumentation applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-SOIC (0.295"", 7.50mm Width) |
| Output Type | Voltage - Buffered |
| Mounting Type | Surface Mount |
| Number of Bits | 8 |
| Data Interface | Parallel |
| Reference Type | External |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 11.4V ~ 16.5V, -5V |
| Voltage - Supply, Digital | 14.25V ~ 15.75V |
| Settling Time | 4µs |
| Supplier Device Package | 24-SOIC |
| Architecture | R-2R |
| Number of D/A Converters | 4 |
| INL/DNL (LSB) | ±1 (Max), ±1 (Max) |
| Differential Output | No |
| Programmable | Not Verified |
