MAX5717AGSD+T
IC DAC 16BIT 14SOICManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX5717AGSD-T is a 16-bit, single-channel digital-to-analog converter (DAC) featuring an R-2R architecture. This component supports SPI and DSP data interfaces, providing flexibility for various system integrations. It delivers an unbuffered voltage output and requires an external reference. The device operates with analog and digital supply voltages ranging from 4.5V to 5.5V, with typical INL/DNL specifications of ±0.25 LSB and ±0.125 LSB respectively. Its settling time is approximately 1.5µs. The MAX5717AGSD-T is housed in a 14-SOIC (0.154", 3.90mm Width) surface-mount package and operates within an industrial temperature range of -40°C to 105°C. This converter is suitable for applications in industrial automation, medical instrumentation, and precision control systems. It is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Output Type | Voltage - Unbuffered |
| Mounting Type | Surface Mount |
| Number of Bits | 16 |
| Data Interface | SPI, DSP |
| Reference Type | External |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Supply, Analog | 4.5V ~ 5.5V |
| Voltage - Supply, Digital | 4.5V ~ 5.5V |
| Settling Time | 1.5µs (Typ) |
| Supplier Device Package | 14-SOIC |
| Architecture | R-2R |
| Number of D/A Converters | 1 |
| INL/DNL (LSB) | ±0.25, ±0.125 |
| Differential Output | No |
| Programmable | Not Verified |
