MAX5591BEUI+T
IC DAC 12BIT V-OUT 28TSSOPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX5591BEUI-T is a versatile 12-bit, 8-channel digital-to-analog converter (DAC) featuring an R-2R architecture. This component offers a buffered voltage output and supports both SPI and DSP data interfaces for flexible integration. It operates across a wide analog supply voltage range of 2.7V to 5.25V and a digital supply range of 1.8V to 5.25V, with an operating temperature of -40°C to 85°C. Key specifications include ±2 LSB INL and ±1 LSB DNL maximum error, and a settling time of 6µs. The device is supplied in a compact 28-TSSOP package, suitable for surface mount applications. This DAC finds utility in applications requiring precise analog signal generation across various industries including industrial automation, consumer electronics, and communications systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 31 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-TSSOP (0.173"", 4.40mm Width) |
| Output Type | Voltage - Buffered |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Data Interface | SPI, DSP |
| Reference Type | External |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 2.7V ~ 5.25V |
| Voltage - Supply, Digital | 1.8V ~ 5.25V |
| Settling Time | 6µs |
| Supplier Device Package | 28-TSSOP |
| Architecture | R-2R |
| Number of D/A Converters | 8 |
| INL/DNL (LSB) | ±2, ±1 (Max) |
| Differential Output | No |
| Programmable | Not Verified |
