MAX5353BEUA
IC DAC 12BIT V-OUT 8UMAXManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX5353BEUA is a 12-bit, single-channel voltage-output digital-to-analog converter (DAC). This R-2R architecture device features an SPI serial interface for data transfer. The MAX5353BEUA offers a low ±2 LSB maximum INL/DNL specification, ensuring precise conversion. It operates with analog and digital supply voltages ranging from 3.15V to 3.6V and includes buffered voltage output. The device supports an external reference and has a typical settling time of 14µs. Supplied in an 8-uMAX/uSOP package, the MAX5353BEUA is suitable for surface mounting and operates within a -40°C to 85°C temperature range. Applications include industrial automation, test and measurement equipment, and consumer electronics.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Output Type | Voltage - Buffered |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Data Interface | SPI |
| Reference Type | External |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 3.15V ~ 3.6V |
| Voltage - Supply, Digital | 3.15V ~ 3.6V |
| Settling Time | 14µs (Typ) |
| Supplier Device Package | 8-uMAX/uSOP |
| Architecture | R-2R |
| Number of D/A Converters | 1 |
| INL/DNL (LSB) | ±2 (Max), ±1 (Max) |
| Differential Output | No |
| Programmable | Not Verified |
Request a Quote
