MAX5352AEUA
IC DAC 12BIT V-OUT 8UMAXManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Digital to Analog Converters (DAC)
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX5352AEUA is a 12-bit, single-channel, voltage-output digital-to-analog converter (DAC) housed in an 8-pin uMAX/uSOP package. This R-2R ladder architecture DAC features an SPI serial interface for data input. The device offers a voltage output that is buffered, providing a typical settling time of 14µs. It operates with analog and digital supply voltages of 5V and supports an operating temperature range of -40°C to 85°C. The MAX5352AEUA is suitable for applications requiring precise voltage control and is commonly found in consumer electronics, industrial control systems, and test and measurement equipment. Its compact 8-TSSOP, 8-MSOP package facilitates surface-mount assembly.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Output Type | Voltage - Buffered |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Data Interface | SPI |
| Reference Type | External |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 5V |
| Settling Time | 14µs (Typ) |
| Supplier Device Package | 8-uMAX/uSOP |
| Architecture | R-2R |
| Number of D/A Converters | 1 |
| INL/DNL (LSB) | ±0.5 (Max), ±1 (Max) |
| Differential Output | No |
| Programmable | Not Verified |
