MAX5405EUB
IC DGT POT 100KOHM 256TAP 10UMAXManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Digital Potentiometers
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX5405EUB is a dual, 100k Ohm digital potentiometer with 256 taps per channel. This device features a linear taper and a voltage supply range of 2.7V to 5.5V. The SPI interface facilitates easy control and programming. Designed for surface mount applications, it is available in a 10-uMAX/uSOP package. The MAX5405EUB offers a typical wiper resistance of 275 Ohms and a temperature coefficient of 35ppm/°C, with a tolerance of ±25%. This component is utilized in various applications including automatic gain control, audio systems, and power supply adjustments across industrial and consumer electronics sectors. The device operates within an ambient temperature range of -40°C to 85°C.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Resistance (Ohms) | 100k |
| Tolerance | ±25% |
| Features | - |
| Packaging | Tube |
| Package / Case | 10-TFSOP, 10-MSOP (0.118"", 3.00mm Width) |
| Mounting Type | Surface Mount |
| Memory Type | Volatile |
| Interface | SPI |
| Configuration | Potentiometer |
| Operating Temperature | -40°C ~ 85°C |
| Number of Taps | 256 |
| Voltage - Supply | 2.7V ~ 5.5V |
| Taper | Linear |
| Supplier Device Package | 10-uMAX/uSOP |
| Resistance - Wiper (Ohms) (Typ) | 275 |
| Temperature Coefficient (Typ) | 35ppm/°C |
| Number of Circuits | 2 |
| Programmable | Not Verified |
