DS1267-100+
IC DGT POT 100KOHM 256TAP 14DIPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Digital Potentiometers
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated DS1267-100- is a dual-channel, 100 kO digital potentiometer featuring 256 discrete resistance steps per channel. This component utilizes a serial interface for control and configuration, enabling precise adjustment of resistance values. With a volatile memory type, it offers a linear taper across its 256 taps, providing fine-grained control suitable for applications requiring adjustable gain, voltage division, or filtering. The DS1267-100- is housed in a 14-PDIP package for through-hole mounting and operates within a temperature range of -40°C to 85°C. Its design is well-suited for industrial automation, audio processing, and control systems where adjustable analog parameters are critical. The device supports a single 5V supply voltage and includes a cascade pin for extending the resistance range.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Resistance (Ohms) | 100k |
| Tolerance | ±20% |
| Features | Cascade Pin |
| Packaging | Tube |
| Package / Case | 14-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Memory Type | Volatile |
| Interface | Serial |
| Configuration | Potentiometer |
| Operating Temperature | -40°C ~ 85°C |
| Number of Taps | 256 |
| Voltage - Supply | 5V |
| Taper | Linear |
| Supplier Device Package | 14-PDIP |
| Resistance - Wiper (Ohms) (Typ) | 400 |
| Temperature Coefficient (Typ) | 750ppm/°C |
| Number of Circuits | 2 |
| Programmable | Not Verified |
