DS1004Z-4
IC DELAY LINE 5TAP 21NS 8SOICManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Delay Lines
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated presents the DS1004Z-4, a nonprogrammable delay line integrated component. This 5-tap device offers a total delay of 21ns, with a tap increment of 4ns and the first tap at 5ns. It operates within a voltage supply range of 4.75V to 5.25V and an ambient temperature range of 0°C to 70°C. The DS1004Z-4 is housed in an 8-SOIC package with a 3.90mm width, suitable for surface mount applications. Industries such as telecommunications, computing, and industrial control systems utilize components like the DS1004Z-4 for precise timing and signal conditioning.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Function | Nonprogrammable |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 4.75V ~ 5.25V |
| Number of Taps/Steps | 5 |
| Delay to 1st Tap | 5ns |
| Number of Independent Delays | 1 |
| Available Total Delays | 21ns |
| Tap Increment | 4 ns |
| Supplier Device Package | 8-SOIC |
