DS1000Z-500N
DELAY LINE 5TAP 500NS IND 8-SOICManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Delay Lines
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated DS1000Z-500N is a 5-tap delay line providing a total delay of 500ns. This component features a tap increment of 100ns, with the delay to the first tap also at 100ns. Designed for surface mount applications, it is housed in an 8-SOIC package with a standard 0.154" (3.90mm) width. Operating at a 5V supply voltage, this delay line is suitable for applications requiring precise timing control in areas such as telecommunications, data acquisition, and signal processing.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Function | Tapped |
| Voltage - Supply | 5V |
| Number of Taps/Steps | 5 |
| Delay to 1st Tap | 100ns |
| Available Total Delays | 500ns |
| Tap Increment | 100 ns |
| Supplier Device Package | 8-SOIC |
