DS1000M-35
DS1000 5-TAP SILICON DELAY LINEManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Delay Lines
Quality Control: Learn More
Delay Line IC Nonprogrammable 5 Tap 35ns 8-DIP (0.300"", 7.62mm)
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 8-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Function | Nonprogrammable |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 4.75V ~ 5.25V |
| Number of Taps/Steps | 5 |
| Delay to 1st Tap | 7ns |
| Number of Independent Delays | 1 |
| Available Total Delays | 35ns |
| Tap Increment | 7 ns |
| Supplier Device Package | 8-PDIP |
