MAX1706EEE
IC REG BOOST ADJ 550MA 16QSOPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: DC DC Switching Regulators
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX1706EEE is a versatile boost switching regulator designed for step-up voltage conversion. This component features an adjustable positive output voltage, capable of delivering up to 5.5V, with a minimum fixed output of 2.5V. It offers a reliable output current of 550mA (switch) and operates within a switching frequency range of 260kHz to 340kHz. The MAX1706EEE utilizes a non-synchronous boost topology and is housed in a 16-QSOP package, suitable for surface mount applications. Its input voltage range spans from 0.9V to 5.5V, making it advantageous for battery-powered devices and portable electronics. This component finds application in consumer electronics, medical devices, and industrial control systems where efficient voltage boosting is critical. The operating temperature range is -40°C to 85°C (TA).
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-SSOP (0.154"", 3.90mm Width) |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Up |
| Current - Output | 550mA (Switch) |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | 260kHz ~ 340kHz |
| Voltage - Input (Max) | 5.5V |
| Topology | Boost |
| Supplier Device Package | 16-QSOP |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | 5.5V |
| Voltage - Input (Min) | 0.9V |
| Voltage - Output (Min/Fixed) | 2.5V |
