MAX5094BAUA+T
IC REG CTRLR MULT TOPOLOGY 8UMAXManufacturer: Analog Devices Inc./Maxim Integrated
Categories: DC DC Switching Controllers
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX5094BAUA-T is a versatile DC-DC controller IC designed for flyback and forward converter topologies. This positive, isolation-capable output controller supports step-up and step-down voltage conversions, making it suitable for a wide range of power management applications. Featuring frequency control, it operates with a switching frequency range of 10kHz to 500kHz and a maximum duty cycle of 49.8%. The device is configured for a single output phase and utilizes a transistor driver for output control. Supplied in an 8-uMAX/uSOP package, it offers a surface mount mounting type for efficient board integration. The operating temperature range is from -40°C to 125°C (TJ). This component is commonly employed in industrial, automotive, and consumer electronics sectors requiring robust and flexible power supply solutions.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118"", 3.00mm Width) |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up/Step-Down |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive, Isolation Capable |
| Frequency - Switching | 10kHz ~ 500kHz |
| Topology | Flyback, Forward Converter |
| Voltage - Supply (Vcc/Vdd) | 7.6V ~ 30V |
| Supplier Device Package | 8-uMAX/uSOP |
| Synchronous Rectifier | No |
| Control Features | Frequency Control |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | 49.8% |
| Clock Sync | No |
| Number of Outputs | 1 |
