MAX774EVKIT
EVAL KIT MAX774 (-5V/-12V/-15V OManufacturer: Analog Devices Inc./Maxim Integrated
Categories: DC/DC & AC/DC (Off-Line) SMPS Evaluation Boards
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX774EVKIT is a fully populated evaluation board designed for the MAX774, MAX775, and MAX776 series of DC/DC inverting regulators. This evaluation kit facilitates the testing and development of power management solutions requiring negative, non-isolated outputs. The board supports an input voltage of 5V and provides a configurable output voltage of -5V, with a maximum output current of 1A. Operating at a switching frequency of 300kHz, the MAX774EVKIT is suitable for applications in consumer electronics, industrial control systems, and battery-powered devices where efficient negative voltage generation is critical. The evaluation board comes packaged in a box and includes the necessary boards for immediate system assessment.
Additional Information
Series: -RoHS Status: Not applicableManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Voltage - Output | -5V |
| Voltage - Input | 5V |
| Current - Output | 1A |
| Frequency - Switching | 300kHz |
| Regulator Topology | Inverting |
| Board Type | Fully Populated |
| Utilized IC / Part | MAX774, MAX775, MAX776 |
| Supplied Contents | Board(s) |
| Main Purpose | DC/DC, Negative Inverter |
| Outputs and Type | 1, Non-Isolated |
