MAX17575EVKITB#

EVKIT FOR 4.5V60V, 1.5A, HIGH-EF

Manufacturer: Analog Devices Inc./Maxim Integrated

Categories: DC/DC & AC/DC (Off-Line) SMPS Evaluation Boards

Quality Control: Learn More

Analog Devices Inc./Maxim Integrated MAX17575EVKITB- evaluation kit showcases the MAX17575, a highly efficient, synchronous buck converter. This fully populated board facilitates rapid prototyping and evaluation of the MAX17575, designed for input voltages ranging from 6V to 60V and delivering a 1.5A output current at a fixed 5V. Operating at a 500kHz switching frequency, this solution minimizes external component size while maintaining high power conversion efficiency. The MAX17575EVKITB- is ideal for applications in industrial automation, automotive systems, and power management where robust and efficient DC-DC conversion is critical.

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:
Technical Details:
PackagingBulk
Voltage - Output5V
Voltage - Input6V ~ 60V
Current - Output1.5A
Frequency - Switching500kHz
Regulator TopologyBuck
Board TypeFully Populated
Utilized IC / PartMAX17575
Supplied ContentsBoard(s)
Main PurposeDC/DC, Step Down
Outputs and Type1, Non-Isolated
