MAX17506EVKITB#
EVKIT FOR 4.5-60V 5A SYNCHRONOUSManufacturer: Analog Devices Inc./Maxim Integrated
Categories: DC/DC & AC/DC (Off-Line) SMPS Evaluation Boards
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX17506EVKITB- is an evaluation kit designed for the MAX17506 synchronous buck converter. This fully populated board facilitates the evaluation of a step-down DC/DC conversion with a wide input voltage range of 4.5V to 60V, capable of delivering up to 5A output current. The evaluation kit operates at a switching frequency of 2.2MHz and is configured for a 3.3V non-isolated output. It is suitable for applications in industrial automation, power over Ethernet (PoE), and high-density power systems where robust voltage regulation is critical. The kit includes necessary boards for immediate testing and analysis of the MAX17506 IC's performance characteristics.
Additional Information
Series: -RoHS Status: Not applicableManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDownload Free CAD Model:
Technical Details:
| Packaging | Box |
| Voltage - Output | 3.3V |
| Voltage - Input | 4.5V ~ 60V |
| Current - Output | 5A |
| Frequency - Switching | 2.2MHz |
| Regulator Topology | Buck |
| Board Type | Fully Populated |
| Utilized IC / Part | MAX17506 |
| Supplied Contents | Board(s) |
| Main Purpose | DC/DC, Step Down |
| Outputs and Type | 1, Non-Isolated |
