MAX17505EVKITB#
EVAL KIT FOR MAX17505Manufacturer: Analog Devices Inc./Maxim Integrated
Categories: DC/DC & AC/DC (Off-Line) SMPS Evaluation Boards
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX17505EVKITB- is a fully populated evaluation board designed to showcase the capabilities of the MAX17505 Himalaya step-down DC/DC converter. This evaluation kit facilitates rapid prototyping and testing of the MAX17505, a non-isolated buck regulator, capable of delivering up to 1.7A output current. It supports a wide input voltage range from 6.5V to 60V, with a fixed 5V output voltage. The device operates at a 500kHz switching frequency, optimizing for efficiency and component size. This evaluation board is ideal for applications in industrial automation, communications infrastructure, and automotive systems where robust voltage regulation is critical. The kit includes the populated evaluation board for immediate use.
Additional Information
Series: HimalayaRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Voltage - Output | 5V |
| Voltage - Input | 6.5V ~ 60V |
| Current - Output | 1.7A |
| Frequency - Switching | 500kHz |
| Regulator Topology | Buck |
| Board Type | Fully Populated |
| Utilized IC / Part | MAX17505 |
| Supplied Contents | Board(s) |
| Main Purpose | DC/DC, Step Down |
| Outputs and Type | 1, Non-Isolated |
