MAX16920BEVKIT+
EVAL KIT FOR MAX16920BManufacturer: Analog Devices Inc./Maxim Integrated
Categories: DC/DC & AC/DC (Off-Line) SMPS Evaluation Boards
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated's MAX16920BEVKIT- is a fully populated evaluation board designed to showcase the capabilities of the MAX16920B DC/DC step-down converter with integrated LDOs. This board facilitates the evaluation of a non-isolated, 4-output power supply solution. The MAX16920B architecture supports a wide input voltage range from 5.5V to 18V, with the evaluation kit configured to demonstrate output voltages of 3.3V and 5V. The device integrates multiple buck regulators, capable of delivering up to 1.5A on one output, along with lower current outputs of 600mA, 150mA, and 150mA. Operating at a switching frequency of 2.2MHz, this evaluation kit is suitable for applications requiring compact and efficient power management, including automotive and industrial control systems. The kit includes the necessary boards for immediate testing and analysis.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Voltage - Output | 3.3V, 3.3V, 5V, 5V |
| Voltage - Input | 5.5V ~ 18V |
| Current - Output | 1.5A, 600mA, 150mA, 150mA |
| Frequency - Switching | 2.2MHz |
| Regulator Topology | Buck |
| Board Type | Fully Populated |
| Utilized IC / Part | MAX16920B |
| Supplied Contents | Board(s) |
| Main Purpose | DC/DC, Step Down with LDO |
| Outputs and Type | 4, Non-Isolated |
