MAX516ACNG+
IC COMPARATOR 4 GEN PUR 24DIPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Comparators
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX516ACNG- is a general-purpose comparator IC featuring four independent elements. This component, housed in a 24-PDIP package, offers CMOS and TTL compatible outputs. It operates from a single or dual supply voltage ranging from 4.75V to 16.5V. The MAX516ACNG- exhibits an input bias current of 0.3µA at 16.5V and a maximum quiescent current of 10mA. Propagation delay is specified at a maximum of 1.5µs. This device is suitable for applications in industrial automation, test and measurement, and consumer electronics. The mounting type is through hole, and it is supplied in tube packaging. Operating temperature range is 0°C to 70°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 24-DIP (0.300"", 7.62mm) |
| Output Type | CMOS, TTL |
| Mounting Type | Through Hole |
| Number of Elements | 4 |
| Type | General Purpose |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply, Single/Dual (±) | 4.75V ~ 16.5V |
| Supplier Device Package | 24-PDIP |
| Propagation Delay (Max) | 1.5µs |
| Current - Quiescent (Max) | 10mA |
| Voltage - Input Offset (Max) | - |
| Current - Input Bias (Max) | 0.3µA @ 16.5V |
| Current - Output (Typ) | - |
| CMRR, PSRR (Typ) | - |
| Hysteresis | - |
