DS2764BE+025/T&R
IC BATT MONITOR LI-ION 16TSSOPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Battery Management
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated DS2764BE-025-T-R is a sophisticated battery monitor IC specifically engineered for lithium-ion battery applications. This device features advanced fault protection, including over-current, over/under-voltage, and short-circuit detection, ensuring robust operational safety. Its I2C interface facilitates seamless communication and integration into complex system architectures. Designed for surface mount applications, the DS2764BE-025-T-R is housed in a compact 16-TSSOP package, measuring 4.40mm in width. This component is typically utilized in portable electronics, automotive systems, and industrial equipment where precise battery management and safety are critical. The component is supplied in Tape & Reel (TR) packaging for efficient manufacturing processes.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-TSSOP (0.173"", 4.40mm Width) |
| Number of Cells | - |
| Mounting Type | Surface Mount |
| Function | Battery Monitor |
| Interface | I2C |
| Operating Temperature | -20°C ~ 70°C (TA) |
| Battery Chemistry | Lithium Ion |
| Supplier Device Package | 16-TSSOP |
| Fault Protection | Over Current, Over/Under Voltage, Short Circuit |
