MAX9724AEUD+
IC AMP CLSS AB STER 45MW 14TSSOPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Audio Amplifiers
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX9724AEUD- is a DirectDrive® Class AB stereo headphone amplifier. This surface-mount component features two channels with a maximum output power of 45mW per channel into a 32 Ohm load. Designed for efficient operation, it supports supply voltages from 2.7V to 5.5V. Key features include integrated depop circuitry, short-circuit protection, thermal protection, and a shutdown function. The device is supplied in a 14-TSSOP package. Applications for this amplifier are found in portable electronics and consumer audio devices.
Additional Information
Series: DirectDrive®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Depop, Short-Circuit and Thermal Protection, Shutdown |
| Packaging | Tube |
| Package / Case | 14-TSSOP (0.173"", 4.40mm Width) |
| Output Type | Headphones, 2-Channel (Stereo) |
| Mounting Type | Surface Mount |
| Type | Class AB |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 2.7V ~ 5.5V |
| Max Output Power x Channels @ Load | 45mW x 2 @ 32Ohm |
| Supplier Device Package | 14-TSSOP |
