MAX144AEPA+
IC ADC 12BIT SAR 8DIPManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX144AEPA- is a 12-bit, 2-input successive approximation analog-to-digital converter (ADC). This component features a single SAR ADC architecture with a 1:1 S/H to ADC ratio. It offers an SPI data interface and accepts a single-ended input. The device operates with analog and digital supply voltages ranging from 2.7V to 5.25V and has a sampling rate of 108kSPS. Housed in an 8-PDIP (0.300", 7.62mm) package for through-hole mounting, the MAX144AEPA- is suitable for applications in the industrial and consumer electronics sectors. The operating temperature range is -40°C to 85°C, and it utilizes an external reference type.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | 8-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Number of Bits | 12 |
| Configuration | MUX-S/H-ADC |
| Data Interface | SPI |
| Reference Type | External |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Analog | 2.7V ~ 5.25V |
| Voltage - Supply, Digital | 2.7V ~ 5.25V |
| Sampling Rate (Per Second) | 108k |
| Input Type | Single Ended |
| Number of Inputs | 2 |
| Supplier Device Package | 8-PDIP |
| Architecture | SAR |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
