MAX1383ATP+T
IC ADC 12BIT SAR 20TQFNManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Analog to Digital Converters (ADC)
Quality Control: Learn More
The Analog Devices Inc./Maxim Integrated MAX1383ATP-T is a 12-bit Analog to Digital Converter (ADC) featuring a Successive Approximation Register (SAR) architecture. This component offers 2 analog-to-digital converters with selectable input configurations supporting 2 or 4 channels. It provides a high sampling rate of 1.25M samples per second. The MAX1383ATP-T supports flexible data interfaces including 3-wire serial, Microwire, QSPI, and SPI, along with both external and internal reference types. Its operating temperature range is -40°C to 125°C. The device is packaged in a 20-TQFN (5x5) with an exposed pad, suitable for surface mount applications. This ADC is utilized in various industries including industrial automation, medical instrumentation, and battery-powered applications.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 34 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Simultaneous Sampling |
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-WQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Number of Bits | 12 |
| Configuration | MUX-S/H-ADC |
| Data Interface | 3-Wire Serial, Microwire, QSPI, SPI |
| Reference Type | External, Internal |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Supply, Analog | 4.75V ~ 5.25V |
| Voltage - Supply, Digital | 1.8V ~ 5.25V |
| Sampling Rate (Per Second) | 1.25M |
| Input Type | Differential, Single Ended |
| Number of Inputs | 2, 4 |
| Supplier Device Package | 20-TQFN (5x5) |
| Architecture | SAR |
| Ratio - S/H:ADC | 2:2 |
| Number of A/D Converters | 2 |
