MAX292CWE
IC FILTER 25KHZ LOWPASS 16SOICManufacturer: Analog Devices Inc./Maxim Integrated
Categories: Active
Quality Control: Learn More
Analog Devices Inc./Maxim Integrated MAX292CWE is an 8th-order, low-pass, switched-capacitor filter IC. This Bessel-type filter offers a cutoff frequency of 25kHz and is housed in a 16-SOIC package suitable for surface-mount applications. The device supports a wide voltage range, accommodating single supplies from 4.75V to 11V and dual supplies from ±2.375V to ±5.5V. It is designed for applications requiring precise analog signal filtering, commonly found in industrial automation, communications infrastructure, and medical instrumentation. The MAX292CWE is supplied in tubes.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-SOIC (0.295"", 7.50mm Width) |
| Filter Type | Bessel, Low Pass Switched Capacitor |
| Mounting Type | Surface Mount |
| Voltage - Supply | 4.75V ~ 11V, ±2.375V ~ 5.5V |
| Number of Filters | 1 |
| Filter Order | 8th |
| Frequency - Cutoff or Center | 25kHz |
| Supplier Device Package | 16-SOIC |
