MAX5974AETE+G3U
IC OFFLINE SWITCH FWD 16TQFNManufacturer: Analog Devices Inc./Maxim Integrated
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
Converter Offline Forward Topology 100kHz ~ 600kHz 16-TQFN (3x3)
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Duty Cycle | 80% |
| Frequency - Switching | 100kHz ~ 600kHz |
| Internal Switch(s) | No |
| Voltage - Breakdown | - |
| Output Isolation | Isolated |
| Topology | Forward |
| Voltage - Supply (Vcc/Vdd) | 7V ~ 26V |
| Supplier Device Package | 16-TQFN (3x3) |
| Fault Protection | Current Limiting, Over Temperature, Short Circuit |
| Voltage - Start Up | 16 V |
| Control Features | EN, Frequency Control, Soft Start, Sync |
