KW DPLS31.MB-5H7H-H5K6-EF-1-120-S-ST-XX
LED WHITE SYNIOS E4014 SMDManufacturer: ams-OSRAM USA INC.
Categories: LED White Lighting
Quality Control: Learn More
The ams-OSRAM USA INC. SYNIOS series KW-DPLS31-MB-5H7H-H5K6-EF-1-120-S-ST-XX is a white surface mount LED designed for lighting applications. This component features a typical forward voltage of 3.15V and operates at a test current of 120mA, with a maximum capability of 180mA. It delivers a luminous flux of 34 lumens at 120mA and 25°C, achieving an efficacy of 90 lm/W. The LED offers a wide viewing angle of 120° and is housed in a 1606 (4014 Metric) SMD package, measuring 4.00mm in length and 1.40mm in width, with a seated height of 0.75mm. Packaged on tape and reel, this component is suitable for high-volume manufacturing in automotive, industrial, and general lighting sectors.
Additional Information
Series: SYNIOSRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 1606 (4014 Metric) |
| Color | White |
| Size / Dimension | 0.157"" L x 0.055"" W (4.00mm x 1.40mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 3.15V |
| Current - Test | 120mA |
| Viewing Angle | 120° |
| Current - Max | 180mA |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | 90 lm/W |
| Height - Seated (Max) | 0.030"" (0.75mm) |
| CCT (K) | - |
| CRI (Color Rendering Index) | - |
| Flux @ 25°C, Current - Test | 34lm (28lm ~ 40lm) |
| Flux @ 85°C, Current - Test | - |
