GW QTLTS2.QM-GWH5-XX58-1-65-R33
LED OSCONIQ WARM WHT 2700K 2835Manufacturer: ams-OSRAM USA INC.
Categories: LED White Lighting
Quality Control: Learn More
The ams-OSRAM USA INC. OSCONIQ® E 2835 series GW-QTLTS2-QM-GWH5-XX58-1-65-R33 is a warm white surface-mount LED designed for demanding lighting applications. Featuring a typical forward voltage of 2.71V and a test current of 65mA, this component delivers 32 lumens with a luminous efficacy of 182 lm/W at 2700K correlated color temperature. The 1113 (2835 Metric) package offers a 120° viewing angle and boasts a CRI of 90, ensuring excellent color rendering. Constructed for reliability, it has a maximum height of 0.031" (0.80mm) and measures 0.110" x 0.138" (2.80mm x 3.50mm). This LED is supplied on tape and reel (TR) and is suitable for general lighting, architectural lighting, and automotive interior lighting solutions.
Additional Information
Series: OSCONIQ® E 2835RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 1113 (2835 Metric) |
| Color | White, Warm |
| Size / Dimension | 0.110"" L x 0.138"" W (2.80mm x 3.50mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 2.71V |
| Current - Test | 65mA |
| Viewing Angle | 120° |
| Current - Max | 200mA |
| Supplier Device Package | 2835 |
| Lumens/Watt @ Current - Test | 182 lm/W |
| Height - Seated (Max) | 0.031"" (0.80mm) |
| CCT (K) | 2700K |
| CRI (Color Rendering Index) | 90 |
| Flux @ 25°C, Current - Test | 32lm (27lm ~ 36lm) |
| Flux @ 85°C, Current - Test | - |
