LSY T675-R1S2-1-0+S1U2-35-0-30-R18-Z
LED TOPLED 633/587 RED/YLW 4PLCCManufacturer: ams-OSRAM USA INC.
Categories: LED Indication - Discrete
Quality Control: Learn More
ams-OSRAM USA INC. Multi TOPLED® LSY-T675-R1S2-1-0-S1U2-35-0-30-R18-Z is a discrete LED component featuring dual-color output. This 4-PLCC package device provides distinct red and yellow light emission with dominant wavelengths of 633nm and 587nm respectively, and peak wavelengths at 645nm and 594nm. Tested at 30mA, the component delivers luminous intensity of 196mcd for red and 445mcd for yellow. Each color exhibits a typical forward voltage of 2.0V. The LED is housed in a compact 3.20mm L x 2.80mm W footprint with a maximum height of 2.10mm, suitable for surface mounting. The lens features a round design with a flat top and a 120° viewing angle. This component is commonly utilized in automotive, industrial, and consumer electronics for visual indication. The LSY-T675-R1S2-1-0-S1U2-35-0-30-R18-Z is supplied in Tape & Reel packaging.
Additional Information
Series: Multi TOPLED®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 4-PLCC |
| Color | Red, Yellow |
| Size / Dimension | 3.20mm L x 2.80mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 196mcd Red, 445mcd Yellow |
| Voltage - Forward (Vf) (Typ) | 2.0V Red, 2.0V Yellow |
| Current - Test | 30mA |
| Viewing Angle | 120° |
| Height (Max) | 2.10mm |
| Wavelength - Peak | 645nm, 594nm |
| Wavelength - Dominant | 633nm, 587nm |
| Supplier Device Package | 4-PLCC |
| Lens Style | Round with Flat Top |
| Lens Size | 2.40mm Dia |
