LA B6SP-DBFA-24-G3R3-140-R33-Z
LED AMBER CLEAR 2PLCC SMD R/AManufacturer: ams-OSRAM USA INC.
Categories: LED Indication - Discrete
Quality Control: Learn More
The ams-OSRAM USA INC. Power SIDELED® LA-B6SP-DBFA-24-G3R3-140-R33-Z is an amber, 617nm discrete LED designed for surface mount applications with a right-angle orientation. This component features a clear, round lens with a flat top, measuring 3.40mm in diameter, and is housed in a 2-SMD, Boomerang package (2-PLCC). It operates at a typical forward voltage of 2.2V and is specified for a test current of 140mA, producing a millicandela rating of 9800mcd with a 120° viewing angle. The dimensions are 4.60mm L x 4.60mm W, with a maximum height of 3.90mm. This LED is supplied on a tape and reel. It finds application in automotive lighting, industrial signaling, and general illumination where precise indication is critical.
Additional Information
Series: Power SIDELED®RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, Boomerang |
| Color | Amber |
| Size / Dimension | 4.60mm L x 4.60mm W |
| Mounting Type | Surface Mount, Right Angle |
| Millicandela Rating | 9800mcd |
| Configuration | - |
| Voltage - Forward (Vf) (Typ) | 2.2V |
| Lens Color | Colorless |
| Current - Test | 140mA |
| Viewing Angle | 120° |
| Height (Max) | 3.90mm |
| Wavelength - Peak | - |
| Wavelength - Dominant | 617nm |
| Supplier Device Package | 2-PLCC |
| Lens Transparency | Clear |
| Lens Style | Round with Flat Top |
| Lens Size | 3.40mm Dia |
