SFH 4943
EMITTER IR ARRAY 950NMManufacturer: ams-OSRAM USA INC.
Categories: LED Emitters - Infrared, UV, Visible
Quality Control: Learn More
ams-OSRAM USA INC. SFH-4943 is a 940nm infrared emitter with a 20° viewing angle. This Through Hole component features a typical forward voltage of 1.35V and a maximum DC forward current of 40mA. At 40mA, it delivers a radiant intensity of 50mW/sr. The SFH-4943 operates within a temperature range of -40°C to 80°C and is housed in a 10-DIP package, supplied in Bulk packaging. This IR emitter is suitable for applications in automotive, medical, and industrial sectors where reliable infrared illumination is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 10-DIP |
| Wavelength | 940nm |
| Mounting Type | Through Hole |
| Type | Infrared (IR) |
| Orientation | Top View |
| Operating Temperature | -40°C ~ 80°C |
| Voltage - Forward (Vf) (Typ) | 1.35V |
| Viewing Angle | 20° |
| Current - DC Forward (If) (Max) | 40mA |
| Radiant Intensity (Ie) Min @ If | 50mW/sr @ 40mA |
