SFH 4650 R33-Z
EMITTER IR SMDManufacturer: ams-OSRAM USA INC.
Categories: LED Emitters - Infrared, UV, Visible
Quality Control: Learn More
ams-OSRAM USA INC. MIDLED series SFH-4650-R33-Z is an infrared emitter designed for surface mount applications. This component features a peak wavelength of 860nm and a typical forward voltage of 1.5V at 100mA. The emitter offers a narrow radiation pattern with a 30° viewing angle, optimized for focused IR illumination.
The SFH-4650-R33-Z is housed in a 2-SMD, No Lead package, suitable for automated assembly processes. Its operating temperature range of -40°C to 100°C (TA) ensures reliable performance in demanding environments. This infrared emitter is commonly utilized in applications such as proximity sensing, machine vision, and security systems, where precise and efficient IR light output is critical. The component is supplied in Tape & Reel packaging for high-volume manufacturing.
Additional Information
Series: MIDLEDRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, No Lead |
| Wavelength | 860nm |
| Mounting Type | Surface Mount |
| Type | Infrared (IR) |
| Orientation | Top View |
| Operating Temperature | -40°C ~ 100°C (TA) |
| Voltage - Forward (Vf) (Typ) | 1.5V |
| Viewing Angle | 30° |
| Current - DC Forward (If) (Max) | 100mA |
| Radiant Intensity (Ie) Min @ If | - |
