SFH 4111
EMITTER IR 950NM 50MA MODULEManufacturer: ams-OSRAM USA INC.
Categories: LED Emitters - Infrared, UV, Visible
Quality Control: Learn More
ams-OSRAM SFH-4111 is an infrared emitter module designed for applications requiring precise optical output. This component operates with a typical forward voltage of 1.25V and a maximum DC forward current of 50mA. Its emission wavelength is centered at 950nm. The SFH-4111 features a dual viewing angle, specified as 60° and 120°, providing flexibility in optical system design. Mounting is facilitated via a chassis mount configuration. Operating within an ambient temperature range of -40°C to 85°C, this module is suitable for demanding environmental conditions. It finds utility in various sectors including industrial automation, security systems, and optical sensing. The component is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module |
| Wavelength | 950nm |
| Mounting Type | Chassis Mount |
| Type | Infrared (IR) |
| Orientation | Top View |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Forward (Vf) (Typ) | 1.25V |
| Viewing Angle | 60°/120° |
| Current - DC Forward (If) (Max) | 50mA |
| Radiant Intensity (Ie) Min @ If | - |
