LZ4-00D100-0000
EMITTER VISIBLE 460NM 1.2A SMDManufacturer: ams-OSRAM USA INC.
Categories: LED Emitters - Infrared, UV, Visible
Quality Control: Learn More
The ams-OSRAM USA INC. LZ4 series, part number LZ4-00D100-0000, is a high-output visible LED emitter. This component features three 460nm emitters and one 400nm emitter, providing a broad spectrum output. The forward voltage for the 460nm emitters is 3.9V, and for the 400nm emitter is 10.5V. It supports a maximum DC forward current of 1.2A and has a wide viewing angle of 110°. Designed for surface mounting, it is housed in an 8-SMD, No Lead Exposed Pad package with top-view orientation. The LZ4-00D100-0000 is rated for an operating junction temperature of 150°C and is supplied in tape and reel packaging. This component is suitable for applications in general lighting, automotive lighting, and display technologies.
Additional Information
Series: LZ4RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SMD, No Lead Exposed Pad |
| Wavelength | 460nm (x3), 400nm |
| Mounting Type | Surface Mount |
| Type | Visible |
| Orientation | Top View |
| Operating Temperature | 150°C (TJ) |
| Voltage - Forward (Vf) (Typ) | 3.9V, 10.5V (x3) |
| Viewing Angle | 110° |
| Current - DC Forward (If) (Max) | 1.2A |
| Radiant Intensity (Ie) Min @ If | - |
