LD 274
EMITTER IR 950NM 100MA RADIALManufacturer: ams-OSRAM USA INC.
Categories: LED Emitters - Infrared, UV, Visible
Quality Control: Learn More
ams-OSRAM USA INC. infrared emitter, part number LD-274, is designed for applications requiring precise infrared emission. This radial component operates with a forward voltage of 1.3V and a maximum forward current of 100mA. It delivers a radiant intensity of 50mW/sr at 100mA, with a narrow viewing angle of 20°. The emitter wavelengths at 950nm make it suitable for various sensing, communication, and automation systems. Its durable construction ensures reliable performance across an operating temperature range of -40°C to 100°C. The through-hole mounting type and radial package facilitate straightforward integration into existing PCB designs. This component is commonly utilized in automotive, industrial, and consumer electronics sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Radial |
| Wavelength | 950nm |
| Mounting Type | Through Hole |
| Type | Infrared (IR) |
| Orientation | Top View |
| Operating Temperature | -40°C ~ 100°C (TA) |
| Voltage - Forward (Vf) (Typ) | 1.3V |
| Viewing Angle | 20° |
| Current - DC Forward (If) (Max) | 100mA |
| Radiant Intensity (Ie) Min @ If | 50mW/sr @ 100mA |
