AS1109-BSSU
IC LED DRVR LINEAR 100MA 16QSOPManufacturer: ams-OSRAM USA INC.
Categories: LED Drivers
Quality Control: Learn More
LED Driver IC 8 Output Linear Shift Register Dimming 100mA 16-QSOP
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-SSOP (0.154"", 3.90mm Width) |
| Voltage - Output | 15V |
| Mounting Type | Surface Mount |
| Number of Outputs | 8 |
| Frequency | 50MHz |
| Type | Linear |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Signage |
| Current - Output / Channel | 100mA |
| Internal Switch(s) | Yes |
| Topology | Shift Register |
| Supplier Device Package | 16-QSOP |
| Dimming | - |
| Voltage - Supply (Min) | 3.15V |
| Voltage - Supply (Max) | 5.5V |
