LY W5AM-HYJZ-36-Z
LED DRAGON PLUS YELLOW 589NM SMDManufacturer: ams-OSRAM USA INC.
Categories: LED Color Lighting
Quality Control: Learn More
The ams-OSRAM USA INC. LY-W5AM-HYJZ-36-Z, part of the Golden DRAGON® Plus series, is a high-performance Yellow LED designed for demanding lighting applications. This 2-SMD, Gull Wing component emits light at a peak wavelength of 589nm, with a typical luminous flux of 52lm (33lm ~ 71lm) at 400mA test current and 25°C. It achieves an efficacy of 59 lm/W under these conditions, with a maximum continuous forward current of 1A and a typical forward voltage of 2.2V. The LED measures 0.276" L x 0.236" W (7.00mm x 6.00mm) and has a seated height of 0.122" (3.10mm). With a wide viewing angle of 170°, this surface-mount device is suitable for automotive, industrial, and architectural lighting solutions. It is supplied in Tape & Reel packaging.
Additional Information
Series: Golden DRAGON® PlusRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, Gull Wing |
| Color | Yellow |
| Wavelength | 589nm (583nm ~ 595nm) |
| Size / Dimension | 0.276"" L x 0.236"" W (7.00mm x 6.00mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 2.2V |
| Current - Test | 400mA |
| Viewing Angle | 170° |
| Current - Max | 1A |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | 59 lm/W |
| Height - Seated (Max) | 0.122"" (3.10mm) |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 52lm (33lm ~ 71lm) |
