LE A S2W-MXMZ-34
LED OSRAM OSTAR AMBER 622NM SMDManufacturer: ams-OSRAM USA INC.
Categories: LED Color Lighting
Quality Control: Learn More
The ams-OSRAM USA INC. OSRAM OSTAR series LE-A-S2W-MXMZ-34 is an 8-SMD module LED designed for demanding lighting applications. This amber LED emits light with a typical wavelength of 622nm, with a range of 613nm to 625nm. It is specified for a maximum forward current of 1A, and at a test current of 700mA, it delivers 230 lumens of luminous flux (180lm ~ 280lm) with a luminous efficacy of 30 lm/W. The forward voltage is typically 2.5V. The compact module measures 0.184" L x 0.228" W (4.68mm x 5.80mm) with a seated height of 0.048" (1.23mm), making it suitable for surface mounting in space-constrained designs. Its wide 120° viewing angle ensures broad light distribution. This component is commonly utilized in automotive lighting, architectural illumination, and industrial signaling. It is supplied in tape and reel packaging.
Additional Information
Series: OSRAM OSTARRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SMD Module |
| Color | Amber |
| Wavelength | 622nm (613nm ~ 625nm) |
| Size / Dimension | 0.184"" L x 0.228"" W (4.68mm x 5.80mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 2.5V |
| Current - Test | 700mA |
| Viewing Angle | 120° |
| Current - Max | 1A |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | 30 lm/W |
| Height - Seated (Max) | 0.048"" (1.23mm) |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 230lm (180lm ~ 280lm) |
