LD W5AM-4T2U-35-0-350-R18
LED DRAGON PLUS BLUE 455NM SMDManufacturer: ams-OSRAM USA INC.
Categories: LED Color Lighting
Quality Control: Learn More
ams-OSRAM USA INC. Golden DRAGON® Plus series blue LED, part number LD-W5AM-4T2U-35-0-350-R18, delivers a typical forward voltage of 3.2V at a test current of 350mA. This surface-mount component features a 2-SMD, Gull Wing package with dimensions of 7.00mm x 6.00mm. Emitting a blue light with a peak wavelength of 455nm (449nm ~ 461nm), it offers a luminous flux of 480mW at 350mA and 25°C. The maximum continuous forward current is rated at 1A. With a wide viewing angle of 170°, this LED is suitable for applications in automotive lighting, signage, and general illumination. Supplied in Tape & Reel (TR) packaging.
Additional Information
Series: Golden DRAGON® PlusRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, Gull Wing |
| Color | Blue |
| Wavelength | 455nm (449nm ~ 461nm) |
| Size / Dimension | 0.276"" L x 0.236"" W (7.00mm x 6.00mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 3.2V |
| Current - Test | 350mA |
| Viewing Angle | 170° |
| Current - Max | 1A |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | - |
| Height - Seated (Max) | 0.122"" (3.10mm) |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 480mW (400mW ~ 560mW) |
Request a Quote
Clients Also Buy
LA W5AM-JXJY-4-0-400-R18-Z-XX
LED DRAGON PLUS AMBER SMD
LA W5AM-JXKX-24-Z
